5.67"(145mm) x 60.25"(1530mm) x 3.93"(100mm) Double Acting Hydraulic Cylinder Hitachi 9111166 AT131413 000621DY3

5.67″(145mm) x 60.25″(1530mm) x 3.93″(100mm) Double Acting Hydraulic Cylinder Hitachi 9111166 AT131413 000621DY3

Original price was: $1,049.95.Current price is: $209.99.

SKU: 904666 Category:

Description

5.67″(145mm) x 60.25″(1530mm) x 3.93″(100mm) DOUBLE ACTING HYDRAULIC CYLINDER
Unused old inventory. Double acting hydraulic cylinder. HITACHI numbers on cylinder 9111166 AT131413 000621DY3.

SPECIFICATIONS
  • Double Acting
  • Bore x Stroke 5.67″(145mm) x 60.25″(1530mm)
  • Barrel Thickness 0.531″
  • Gland Retainer Bolt on gland
  • Pressure 3000 PSI
  • Rod Dia. 3.93″(100mm)
  • Ports 4 bolt 1″ code 62 flange size 16
  • Retracted Length 84″
  • Gland Face to Rod Pin Center 5.75″
  • Shpg. 685 lbs.
END MOUNTINGS
  • Rod End Tang
  • Width 3.92″
  • Pin-Center-To-Tang-End 3.59″
  • Pin Hole 3.94″(100mm)
  • Base End Tang
  • Width 3.92″
  • Pin-Center-To-Tang-End 3.64″
  • Pin Hole 3.94″(100mm)
