Description
Product details
| Gross weight |
67 kg |
| Net weight |
62.63 kg |
| Gross weight |
67 kg |
| Net weight |
62.63 kg |
| EAN |
5702428562881 |
| Air flow @ 50Hz [m³/h] |
1550 m3/h |
| Applications |
LBP |
| Approval standard |
CE
EAC |
| Compressor model |
NTZ048-5B |
| Compressor power supply [V/Ph/Hz] |
230/1/50 |
| Condenser type |
A7 |
|
OP-LCQN048NTA02G |
| Electrical code |
G |
| Fan blade size [mm] |
350 mm |
| Fan cowl/grill type |
Cowl |
| Fan current @ 50Hz [A] |
0.35 A |
| Fan power consumption @ 50Hz [W] |
75 W |
| Fan power output @ 50Hz [W] |
13 W |
| Fan power supply [V/Ph/Hz] |
230/1/50 |
| Fan voltage @ 50Hz (max) [V] [Max] |
230 V |
| Fan voltage @ 50Hz (max) [V] [Min] |
207 V |
| Length [mm] |
650 mm |
| Liquid line connection [in] |
3/8 in |
| Liquid line connection type |
Solder |
| LRA |
37 A |
| MCC |
11.43 A |
| Model number |
OP-LCQN048NTA02G |
| No. of phases (compressor) |
1 |
| No. of phases (fan) |
1 |
| Number of fans |
1 |
| Receiver approval |
CE |
| Receiver volume [L] |
3 L |
| Refrigerant |
R404A
R452A |
| Segment usage |
Low Back Pressure |
| Sound power @ 50Hz [db(A)] |
73 dBA |
| Suction connection type |
Solder |
| Total height [mm] |
545 mm |
| Type |
Optyma™ |
| Type designation |
Condensing Units |
| Version |
A02 |
| Voltage 50Hz [V] |
207 V |
| Voltage 50Hz [V] [Max] |
253 V |
| Width [mm] |
630 mm |
| Air flow @ 50Hz [m³/h] |
1550 m3/h |
| Applications |
LBP |
| Approval standard |
CE
EAC |
| Compressor model |
NTZ048-5B |
| Compressor power supply [V/Ph/Hz] |
230/1/50 |
| Condenser type |
A7 |
|
OP-LCQN048NTA02G |
| Electrical code |
G |
| Fan blade size [mm] |
350 mm |
| Fan cowl/grill type |
Cowl |
| Fan current @ 50Hz [A] |
0.35 A |
| Fan power consumption @ 50Hz [W] |
75 W |
| Fan power output @ 50Hz [W] |
13 W |
| Fan power supply [V/Ph/Hz] |
230/1/50 |
| Fan voltage @ 50Hz (max) [V] [Max] |
230 V |
| Fan voltage @ 50Hz (max) [V] [Min] |
207 V |
| Length [mm] |
650 mm |
| Liquid line connection [in] |
3/8 in |
| Liquid line connection type |
Solder |
| LRA |
37 A |
| MCC |
11.43 A |
| Model number |
OP-LCQN048NTA02G |
| No. of phases (compressor) |
1 |
| No. of phases (fan) |
1 |
| Number of fans |
1 |
| Receiver approval |
CE |
| Receiver volume [L] |
3 L |
| Refrigerant |
R404A
R452A |
| Segment usage |
Low Back Pressure |
| Sound power @ 50Hz [db(A)] |
73 dBA |
| Suction connection type |
Solder |
| Total height [mm] |
545 mm |
| Type |
Optyma™ |
| Type designation |
Condensing Units |
| Version |
A02 |
| Voltage 50Hz [V] |
207 V |
| Voltage 50Hz [V] [Max] |
253 V |
| Width [mm] |
630 mm |
Type designation: Condensing Units, Type: Optyma™, Model number: OP-LCQN048NTA02G, Refrigerant: R404A; R452A, Segment usage: Low Back Pressure, No. of phases (compressor): 1
