Description
Product details
| Gross weight |
21 kg |
| Net weight |
18 kg |
| Gross weight |
21 kg |
| Net weight |
18 kg |
| EAN |
5702428565646 |
| Air flow @ 50Hz [m³/h] |
518 m3/h |
| Applications |
LBP |
| Approval standard |
CE
EAC |
| Compressor model |
NL8.4CLX |
| Compressor power supply [V/Ph/Hz] |
230/1/50 |
| Condenser type |
BG_3 |
|
OP-LCHC008NLA04G |
| Electrical code |
G |
| Fan blade size [mm] |
230 mm |
| Fan cowl/grill type |
Grill |
| Fan current @ 50Hz [A] |
0.25 A |
| Fan diameter [mm] |
230 mm |
| Fan power consumption @ 50Hz [W] |
36 W |
| Fan power output @ 50Hz [W] |
10 W |
| Fan power supply [V/Ph/Hz] |
230/1/50 |
| Fan voltage @ 50Hz (max) [V] [Max] |
253 V |
| Fan voltage @ 50Hz (max) [V] [Min] |
207 V |
| Liquid line connection [mm] |
6 mm |
| Model number |
OP-LCHC008 |
| No. of phases (compressor) |
1 |
| No. of phases (fan) |
1 |
| Number of fans |
1 |
| Receiver approval |
CE |
| Receiver volume [L] |
1.1 L |
| Refrigerant |
R404A
R507 |
| RLA |
2.5 A |
| Segment usage |
Low Back Pressure |
| Suction connection size [mm] |
8 µm |
| Type |
Optyma™ |
| Type designation |
Condensing Units |
| Version |
A04 |
| Voltage 50Hz [V] |
207 V |
| Voltage 50Hz [V] [Max] |
253 V |
| Air flow @ 50Hz [m³/h] |
518 m3/h |
| Applications |
LBP |
| Approval standard |
CE
EAC |
| Compressor model |
NL8.4CLX |
| Compressor power supply [V/Ph/Hz] |
230/1/50 |
| Condenser type |
BG_3 |
|
OP-LCHC008NLA04G |
| Electrical code |
G |
| Fan blade size [mm] |
230 mm |
| Fan cowl/grill type |
Grill |
| Fan current @ 50Hz [A] |
0.25 A |
| Fan diameter [mm] |
230 mm |
| Fan power consumption @ 50Hz [W] |
36 W |
| Fan power output @ 50Hz [W] |
10 W |
| Fan power supply [V/Ph/Hz] |
230/1/50 |
| Fan voltage @ 50Hz (max) [V] [Max] |
253 V |
| Fan voltage @ 50Hz (max) [V] [Min] |
207 V |
| Liquid line connection [mm] |
6 mm |
| Model number |
OP-LCHC008 |
| No. of phases (compressor) |
1 |
| No. of phases (fan) |
1 |
| Number of fans |
1 |
| Receiver approval |
CE |
| Receiver volume [L] |
1.1 L |
| Refrigerant |
R404A
R507 |
| RLA |
2.5 A |
| Segment usage |
Low Back Pressure |
| Suction connection size [mm] |
8 µm |
| Type |
Optyma™ |
| Type designation |
Condensing Units |
| Version |
A04 |
| Voltage 50Hz [V] |
207 V |
| Voltage 50Hz [V] [Max] |
253 V |
Type designation: Condensing Units, Type: Optyma™, Model number: OP-LCHC008, Refrigerant: R404A; R507, Segment usage: Low Back Pressure, No. of phases (compressor): 1
