Description
Product details
| Gross weight |
11.9 kg |
| Net weight |
11.7 kg |
| Application energy level |
Energy-optimized |
| Applications |
MBP |
| Base plate type |
EU small |
| Brand technique |
Reciprocating compressor |
| Capacity control |
Fixed speed |
| Colour |
Black |
| Compressor power supply [V/Ph/Hz] |
220-240/1/50 |
| Configuration code |
Single |
|
NLE11MN |
| Discharge connection angle [°] |
21 ° |
| Discharge connection comments |
Rubber plug |
| Discharge connection diameter [mm] |
6.2 mm |
| Discharge connection material |
Copper |
| Economizer |
No |
| Free gas volume [cm3] |
2360 cm3 |
| Frequency [Hz] |
50 |
| Height from baseplate [mm] |
197 mm |
| High value of nominal voltage at 50Hz [V] |
240 V |
| High value of nominal voltage at 60Hz [V] |
0 V |
| High value of voltage range at 50Hz [V] |
264 V |
| High value of voltage range at 60Hz [V] |
0 V |
| Length [mm] |
252 mm |
| Liquid injection |
No |
| Low value of nominal voltage at 50Hz [V] |
220 V |
| Low value of nominal voltage at 60Hz [V] |
0 V |
| Low value of voltage range at 50Hz [V] |
198 V |
| Low value of voltage range at 60Hz [V] |
0 V |
| Model number |
NLE11MN |
| Motor type |
CSIR
RSCR
RSIR |
| No. of phases (compressor) |
1 |
| Oil quantity [cm3] |
300 cm3 |
| Oil type |
POE |
| Packing format |
Industrial pack |
| Packing quantity |
80 |
| Phase |
1 |
| Process connection angle [°] |
25 ° |
| Process connection comments |
Rubber plug |
| Process connection diameter [mm] |
6.2 mm |
| Process connection material |
Copper |
| Refrigerant |
R290 |
| Refrigerant charge [kg] [Max] |
0.15 kg |
| Rotational speed at 50Hz [rpm] |
2900 rpm |
| Rotational speed at 60Hz [rpm] |
0 rpm |
| Run capacitor capacitance |
4 µF |
| Segment usage |
Refrigeration MT |
| Suction connection angle [°] |
15 ° |
| Suction connection comments |
Rubber plug |
| Suction connection diameter [mm] |
8.2 mm |
| Suction connection material |
Copper |
| Swept volume [cm3] |
11.15 cm3 |
| Technology |
Reciprocating |
| Total height [mm] |
203 mm |
| Type |
NL |
| Type designation |
Compressor |
| Voltage 50Hz [V] |
220 V |
| Voltage 50Hz [V] [Max] |
240 V |
| Width [mm] |
166 mm |
| Winding temperature short term [°C] [Max] |
135 °C |
| Winding temperature stat [°C] [Max] |
125 °C |
| Application energy level |
Energy-optimized |
| Applications |
MBP |
| Base plate type |
EU small |
| Brand technique |
Reciprocating compressor |
| Capacity control |
Fixed speed |
| Colour |
Black |
| Compressor power supply [V/Ph/Hz] |
220-240/1/50 |
| Configuration code |
Single |
|
NLE11MN |
| Discharge connection angle [°] |
21 ° |
| Discharge connection comments |
Rubber plug |
| Discharge connection diameter [mm] |
6.2 mm |
| Discharge connection material |
Copper |
| Economizer |
No |
| Free gas volume [cm3] |
2360 cm3 |
| Frequency [Hz] |
50 |
| Height from baseplate [mm] |
197 mm |
| High value of nominal voltage at 50Hz [V] |
240 V |
| High value of nominal voltage at 60Hz [V] |
0 V |
| High value of voltage range at 50Hz [V] |
264 V |
| High value of voltage range at 60Hz [V] |
0 V |
| Length [mm] |
252 mm |
| Liquid injection |
No |
| Low value of nominal voltage at 50Hz [V] |
220 V |
| Low value of nominal voltage at 60Hz [V] |
0 V |
| Low value of voltage range at 50Hz [V] |
198 V |
| Low value of voltage range at 60Hz [V] |
0 V |
| Model number |
NLE11MN |
| Motor type |
CSIR
RSCR
RSIR |
| No. of phases (compressor) |
1 |
| Oil quantity [cm3] |
300 cm3 |
| Oil type |
POE |
| Packing format |
Industrial pack |
| Packing quantity |
80 |
| Phase |
1 |
| Process connection angle [°] |
25 ° |
| Process connection comments |
Rubber plug |
| Process connection diameter [mm] |
6.2 mm |
| Process connection material |
Copper |
| Refrigerant |
R290 |
| Refrigerant charge [kg] [Max] |
0.15 kg |
| Rotational speed at 50Hz [rpm] |
2900 rpm |
| Rotational speed at 60Hz [rpm] |
0 rpm |
| Run capacitor capacitance |
4 µF |
| Segment usage |
Refrigeration MT |
| Suction connection angle [°] |
15 ° |
| Suction connection comments |
Rubber plug |
| Suction connection diameter [mm] |
8.2 mm |
| Suction connection material |
Copper |
| Swept volume [cm3] |
11.15 cm3 |
| Technology |
Reciprocating |
| Total height [mm] |
203 mm |
| Type |
NL |
| Type designation |
Compressor |
| Voltage 50Hz [V] |
220 V |
| Voltage 50Hz [V] [Max] |
240 V |
| Width [mm] |
166 mm |
| Winding temperature short term [°C] [Max] |
135 °C |
| Winding temperature stat [°C] [Max] |
125 °C |
Refrigerant: R290, Segment usage: Refrigeration MT, Compressor power supply [V/Ph/Hz]: 220-240/1/50
