Description
Product details
| Gross weight |
0.33 kg |
| Net weight |
0.29 kg |
| Gross weight |
0.33 kg |
| Net weight |
0.29 kg |
| EAN |
5702428053020 |
| Approval |
EAC
LLC CDC TYSK |
| Body material |
Brass |
| Capillary tube length [in] |
59 in |
| Capillary tube length [mm] |
1500 mm |
| Category |
Art. 4, par. 3 |
| Connection material |
Brass |
| Direction |
Angleway |
| Equalization connection type |
FLARE |
| Equalization size [in] |
1/4 IN |
| Flow direction |
Single-flow |
| Flow direction indicator |
Embossed 1-way arrow |
| Fluid Group |
II |
| Inlet connection type |
FLARE |
| Inlet size [in] |
3/8 IN |
| Max. Working Pressure [bar] |
34 bar |
| Max. Working Pressure [psig] |
500 psig |
| MOP Point [psig] |
MOP 20 |
| MOP Point [°C] |
-65 °C |
| MOP Point [°F] |
-85 °F |
| Outlet connection type |
FLARE |
| Outlet size [in] |
1/2 IN |
| Packing format |
Multi pack |
| Parts included |
Bulb strap |
| Parts Program name |
T2/TE2 |
| Pressure equalization |
Externally equalized |
| Product accessories |
TXV accessories |
| Product family name |
T2 |
| Product group |
Expansion valves |
| Product name |
Thermostatic expansion valve |
| Quantity per packing format |
20 pc |
| Refrigerants |
R23 |
| Serviceable |
TXV spare parts |
| Static Superheat (SS) [°C] |
4 °C |
| Static Superheat (SS) [°F] |
7.2 °F |
| Superheat setting |
Adjustable |
| Temperature range [°C] [Max] |
-70 °C |
| Temperature range [°C] [Min] |
-100 °C |
| Temperature range [°F] [Max] |
-94 °F |
| Temperature range [°F] [Min] |
-148 °F |
| Type |
TE 2 |
| Approval |
EAC
LLC CDC TYSK |
| Body material |
Brass |
| Capillary tube length [in] |
59 in |
| Capillary tube length [mm] |
1500 mm |
| Category |
Art. 4, par. 3 |
| Connection material |
Brass |
| Direction |
Angleway |
| Equalization connection type |
FLARE |
| Equalization size [in] |
1/4 IN |
| Flow direction |
Single-flow |
| Flow direction indicator |
Embossed 1-way arrow |
| Fluid Group |
II |
| Inlet connection type |
FLARE |
| Inlet size [in] |
3/8 IN |
| Max. Working Pressure [bar] |
34 bar |
| Max. Working Pressure [psig] |
500 psig |
| MOP Point [psig] |
MOP 20 |
| MOP Point [°C] |
-65 °C |
| MOP Point [°F] |
-85 °F |
| Outlet connection type |
FLARE |
| Outlet size [in] |
1/2 IN |
| Packing format |
Multi pack |
| Parts included |
Bulb strap |
| Parts Program name |
T2/TE2 |
| Pressure equalization |
Externally equalized |
| Product accessories |
TXV accessories |
| Product family name |
T2 |
| Product group |
Expansion valves |
| Product name |
Thermostatic expansion valve |
| Quantity per packing format |
20 pc |
| Refrigerants |
R23 |
| Serviceable |
TXV spare parts |
| Static Superheat (SS) [°C] |
4 °C |
| Static Superheat (SS) [°F] |
7.2 °F |
| Superheat setting |
Adjustable |
| Temperature range [°C] [Max] |
-70 °C |
| Temperature range [°C] [Min] |
-100 °C |
| Temperature range [°F] [Max] |
-94 °F |
| Temperature range [°F] [Min] |
-148 °F |
| Type |
TE 2 |
Refrigerants: R23, Inlet connection type: FLARE, Outlet connection type: FLARE
