Description
Product details
| Gross weight |
0.19 kg |
| Net weight |
0.18 kg |
| Gross weight |
0.19 kg |
| Net weight |
0.18 kg |
| EAN |
5702428054010 |
| Actuator size |
9 mm |
| Ambient temperature range [°C] [Max] |
50 °C |
| Ambient temperature range [°C] [Min] |
-40 °C |
| Ambient temperature range [°F] [Max] |
122 °F |
| Ambient temperature range [°F] [Min] |
-40 °F |
| Approval |
LLC CDC TYSK |
| Cable length [in] |
40 in |
| Cable length [m] |
1 m |
| Coil connection |
CABLE |
| Coil fastening |
Clip-on |
| Colour |
Blue |
| Compliance |
EN 60730-1 |
| Conductor area [mm2] |
3 x 0.75 mm2 |
| Electrical connection |
Cable |
| Electrical connector |
3 core cable |
| Enclosure rating IP |
IP67 |
| Identical product |
042N7688 |
| Packing format |
Industrial pack |
| Parts Program name |
EV220W |
| Power consumption [W] DC |
12 W |
| Product accessories |
Solenoid coil accessories |
| Product group |
Solenoid valves |
| Product name |
Solenoid coil |
| Quantity per packing format |
20 pc |
| Rel. Humidity [% RH] [Max] |
100 % |
| Rel. Humidity [% RH] [Min] |
0 % |
| Serviceable |
No |
| Spare part number |
042N7696 |
| Supply voltage [V] DC |
12 V |
| Type |
AU012DS |
| Type designation |
AU012DS |
| Actuator size |
9 mm |
| Ambient temperature range [°C] [Max] |
50 °C |
| Ambient temperature range [°C] [Min] |
-40 °C |
| Ambient temperature range [°F] [Max] |
122 °F |
| Ambient temperature range [°F] [Min] |
-40 °F |
| Approval |
LLC CDC TYSK |
| Cable length [in] |
40 in |
| Cable length [m] |
1 m |
| Coil connection |
CABLE |
| Coil fastening |
Clip-on |
| Colour |
Blue |
| Compliance |
EN 60730-1 |
| Conductor area [mm2] |
3 x 0.75 mm2 |
| Electrical connection |
Cable |
| Electrical connector |
3 core cable |
| Enclosure rating IP |
IP67 |
| Identical product |
042N7688 |
| Packing format |
Industrial pack |
| Parts Program name |
EV220W |
| Power consumption [W] DC |
12 W |
| Product accessories |
Solenoid coil accessories |
| Product group |
Solenoid valves |
| Product name |
Solenoid coil |
| Quantity per packing format |
20 pc |
| Rel. Humidity [% RH] [Max] |
100 % |
| Rel. Humidity [% RH] [Min] |
0 % |
| Serviceable |
No |
| Spare part number |
042N7696 |
| Supply voltage [V] DC |
12 V |
| Type |
AU012DS |
| Type designation |
AU012DS |
Product name: Solenoid coil, Type: AU012DS, Enclosure rating IP: IP67, Coil connection: CABLE, Actuator size: 9 mm
