Description
Type Code MCI 15 , Weight 0.720 Kg , Approval CE, EAC, UL More details
Covering the power range from 0.1 to 22 kW, the MCI soft starters are ideal for a wide range of start and stop applications where smooth operation is required. Use them on pumps, compressors, fans, conveyors, gear or belt driven machinery and countless other types of equipment. MCI is designed for unlimited number of operations per hour and is just as easy to specify and install as an ordinary contactor. Individual adjustable acceleration and deceleration times, up to 60 seconds Initial torque adjustable from 0 – 85% Breakaway function (Kick Start) Universal control voltage: 24-480V ac/dc Automatic detection of missing phases Automatic adaptation to 50/60 Hz LED status indicator Built-in varistor protection Unlimited start/stop operations per hour Optional aux. contacts Compact DIN rail mountable design
| Type Code | MCI 15 |
| Weight | 0.720 Kg |
| Approval | CE, EAC, UL |
| Control volt. | 24 – 480 V |
| Control volt., 50/60 Hz | 24 – 480 V |
| Controlled phases | 2 |
| EAN no. | 5702423108701 |
| Fixed setting | No |
| Max. load | 15 A |
| Prod. description | SOFT START MOTOR CONTACTOR |
| Prod. group | Contactors and motor starters |
| Prod. name | Electronic soft starter |
| Supply volt. | 600 V |
| UL approval file name | E198251 |
