Description
Product details
| Gross weight |
1.52 kg |
| Net weight |
0.9 kg |
| Gross weight |
1.52 kg |
| Net weight |
0.9 kg |
| EAN |
5702428559393 |
| Access port |
YES |
| Approval |
CE
C UL US LISTED |
| Body material |
Brass |
| Connection material |
Copper |
| Cv value [gal/min] |
48.9 gal/min |
| Direction |
Straightway |
| Equipment |
Cap w. wire seal (EN 378 comp) |
| Flow direction |
Bi-flow |
| Flow direction indicator |
Laser engraved 2-way arrow |
| Inlet connection type |
SOLDER, ODF |
| Inlet size [in] |
1 1/8 IN |
| Kv value [m³/h] |
42.3 m3/h |
| Max. test pressure [bar] |
200 bar |
| Max. test pressure [psig] |
2900 psig |
| Max. Working Pressure [bar] |
140 bar |
| Max. Working Pressure [psig] |
2031 psig |
| Outlet connection type |
SOLDER, ODF |
| Outlet size [in] |
1 1/8 IN |
| Packing format |
Multi pack |
| Parts included |
Schrader valve |
| Product family name |
GBCT |
| Product group |
Shut-off and regulating valves |
| Product name |
Shut-off ball valve |
| Quantity per packing format |
4 pc |
| Refrigerants |
R744 |
| Temperature range [°C] [Max] |
149 °C |
| Temperature range [°C] [Min] |
-40 °C |
| Temperature range [°F] [Max] |
300 °F |
| Temperature range [°F] [Min] |
-40 °F |
| Type |
GBCT 28s |
| Access port |
YES |
| Approval |
CE
C UL US LISTED |
| Body material |
Brass |
| Connection material |
Copper |
| Cv value [gal/min] |
48.9 gal/min |
| Direction |
Straightway |
| Equipment |
Cap w. wire seal (EN 378 comp) |
| Flow direction |
Bi-flow |
| Flow direction indicator |
Laser engraved 2-way arrow |
| Inlet connection type |
SOLDER, ODF |
| Inlet size [in] |
1 1/8 IN |
| Kv value [m³/h] |
42.3 m3/h |
| Max. test pressure [bar] |
200 bar |
| Max. test pressure [psig] |
2900 psig |
| Max. Working Pressure [bar] |
140 bar |
| Max. Working Pressure [psig] |
2031 psig |
| Outlet connection type |
SOLDER, ODF |
| Outlet size [in] |
1 1/8 IN |
| Packing format |
Multi pack |
| Parts included |
Schrader valve |
| Product family name |
GBCT |
| Product group |
Shut-off and regulating valves |
| Product name |
Shut-off ball valve |
| Quantity per packing format |
4 pc |
| Refrigerants |
R744 |
| Temperature range [°C] [Max] |
149 °C |
| Temperature range [°C] [Min] |
-40 °C |
| Temperature range [°F] [Max] |
300 °F |
| Temperature range [°F] [Min] |
-40 °F |
| Type |
GBCT 28s |
Max. Working Pressure [bar]: 140.0, Refrigerants: R744, Inlet connection type: SOLDER, ODF, Inlet size [in]: 1 1/8 IN, Access port: YES
